● Compact body, exquisite design
● Side-opening cover, easy for paper loading
● Gear dust proof, long printer life
● Fast printing speed 250mm/s
● Support multi-language printing
● Support 1D & 2D barcode printing
● A cost-effective POS receipt printer for catering, retail, hospitality, etc.
，
| Model | TP80N-M | TP80N-H | |
| Print parameter | Printing Method | Direct Thermal | |
| Resolution | 203 DPI/180 DPI | ||
| Printing Width | 72 mm(Default)/48 mm | ||
| Printing Speed | Max.200 mm/s | Max.250mm/s | |
| Protocol | ESC/POS(support page mode) | ||
| Media | Media Type | Continuous thermal receipt/recycled thermal paper | |
| Media Width | MAX.80 mm | ||
| Paper Roll Diameter | Max Φ 80.0 mm | ||
| Paper exit | Front exit | ||
| Barcode | 1D | UPC-A, UPC-E, EAN-8, EAN-13, CODE39, ITF, CODABAR,CODE128, CODE93 | |
| 2D | QR Code,PDF417 | ||
| Font | Chinese | Simplified/Traditional (24×24) | |
| Alphanumeric | Font A 12×24,Font B 9×17 | ||
| Character Set | Chinese, International Character Sets, Korean, Japanese | ||
| Interface | Standard | 1*USB Type-B，Ethernet，Cash drawer | |
| Optional | Wi-Fi，Bluetooth | ||
| Beeper | Type | Built-in buzzer, external buzzer (optional) | |
| Sensor | Standard | Over-temperature detection, paper out detection, cover up detection,cutter jam detection | |
| Memory | RAM | 4 MB | |
| Flash | 4 MB | ||
| Power Supply | Input | AC 100～240 V，50/60 Hz | |
| Output | DC 24V 1.5A | ||
| Software | Driver | Windows 7/8/10，Windows Server 2008/2012/2016 | |
| Linux，Javapos，OPOS，MacOS | |||
| Utility | Windows 7/8/10，Windows Server 2008/2012/2016 | ||
| Reliability | TPH | 100 km | |
| Cutter life | 1 million | ||
| Environment | Operating temperature | 0℃～45℃/25%～85%RH | |
| Storage temperature | -20℃～60℃/5%～95%RH | ||
| Printer Dimension | 45*123.5*121.6 mm (W*D*H) | ||
| Certification | CCC，CE，FCC | ||
