• Dual-wall frame, robust and sturdy structure
• ARM9 32-bit processor with 128 MB SDRAM,256 MB Flash memory
• Full-width, moveable and multi-position media sensors
• USB, Ethernet, Serial as standard, optional plug and play Bluetooth or Wi-Fi
• Bundle Seagull Windows Driver and Bartender
• ZPL, DPL, EPL, TSPL emullation supported
• Various accessories include external roll holder, peeling module, cutter module
，
| Item | HT600 | HT630 | |
| Printing | Printing Method | Thermal transfer | Thermal transfer |
| Resolution | 203DPI | 300DPI | |
| Max. Printing Speed | 152mm/s | 100 mm/s | |
| Max. Printing Width | 108mm | 106mm | |
| Max. Printing Length | 1200mm | 1200mm | |
| CPU | 32-bit RISC CPU | ||
| Memory | RAM | 128MB | |
| Flash | 256MB | ||
| Detection | Sensor | Out-of-paper detection, gap detection, ribbon detection, black mark | |
| detection, cover-opening detection | |||
| Media | Types | Black mark label, punched hole label, folding or rolling die cutting label | |
| Width | 1'' (25.4mm) ‒ 4.33'' (110mm) | ||
| Height | 0.0787'' (20mm)‒ 9.84'' (250mm) | ||
| Thickness | 0.002''(60um)-0.01''(250um) | ||
| Label Roll Diameter | 5''(127 mm) Max | ||
| Core Diameter | 0.5''(12.7 mm), 1''(25.4 mm). 1.5''(38 mm) | ||
| Ribbon | Type | Wax, Wax/Resin, Resin | |
| Width | 2'' (50mm) ‒ 4.38'' (118mm) | ||
| Length | 328'(100 m) | ||
| Core Diamete | 0.5''(12.7 mm) | ||
| Programming Language | ZPL, TSPL,EPL,DPL | ||
| Software | Label Design Software | HPRT BarTender Ultralite (professional and higher versions are | |
| available for trial) | |||
| Driver | Windows Vista7,8,10, Server 2012/2016/2018 | ||
| Resident Fonts | Bitmap fonts | 6, 8, 12, 16, 32, OCR A & B. 90°, 180°, 270° rotatable and 10 magnification. | |
| TTF fonts | CG Triumvirate™times expandable in horizontal and vertical | ||
| directions, simplified Chinese. | |||
| Code Pages | DOS437,720,737,755,775,850,852,855,856,857,858,860,862,863,864,865,866, | ||
| Windows 1250,1251,1252,1253,1254,1255,1256,1257,1258, | |||
| ISO8859-1,-2,-3,-4,-5,-6,-8,-9,-15 | |||
| Barcodes | 1D | Code 39, Code 93, Code 128UCC, Code 128 subset A, B, C, Codabar, Interleave | |
| 2 of 5, EAN-8, EAN-13, EAN-128,UPC-A, UPC-E, EAN and UPC 2 (5) digits | |||
| add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11 | |||
| 2D | PDF417, Maxicode, DataMatrix, QR Code, Aztec | ||
| Interfaces | Standard | USB, Serial,Ethernet | |
| Optional | Bluetooth 4.0/BLE, WiFi | ||
| Control Panel | Two-color status light: power indicator, status indicator | ||
| Four control buttons: power button, pause button, feed button, cancel button | |||
| Power Supply | Power Switch | ||
| Input: AC 100-240 V, 50/60 Hz | |||
| Output: DC 24 V / 2 A | |||
| Environment | Operation | 41℉(5℃) to 104℉(40℃) , humidity 30% to 85% ,non-condensing | |
| Storage | -4℉(-20℃) to 122℉(50℃), J31humidity 10% to 90% ,non-condensing | ||
| Physical Characteristic | Dimension(L*H*W) | 251.78*201.1*174.48 | |
| Weight | 2.014 KG | ||
| Options & Accessory | Peeler module, cutter module, external label roll holder | ||
| Agency Approval | CCC,CE,FCC,RoHS | ||
